Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer
Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer
Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer
Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer
Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer
1 / 5
Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer
Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer
Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer
Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer
Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer

Dry Type Isolation Transformer Cast Resin Copper / Aluminium Transformer

Send Inquiry

Product Description

Products Description
Dry-type transformer main
⚡
TSTY can supply Voltage include 6.6kv~35kv, Capacity covers 30kva~5000kva.
🛡️
Dry-type transformers are suitable for specific scenarios with strict fire protection requirements, such as high-rise buildings, subways, hospitals, data centers, etc., due to their advantages such as fire prevention, environmental protection, and easy maintenance.
🌵
Dry-type transformers are more suitable for hot areas (no oil cooling required), and their maintenance-free characteristics are also suitable for areas with harsh climates such as deserts.
🌐
High-frequency, low-noise, and intelligent (IoT monitoring) dry-type transformers have become a new growth point in the high-end market.
Transformer detail 1
Transformer detail 2
Technical Drawing
Rated capacity (KVA) Connection symbol High-voltage (kv) Low-voltage (kv) No-load loss (W) Load loss (W) No-load current (%) Short circuit impedance (%)
30Yyn0 or Dyn11110.41907102.44
5010.527010002.4
801037013801.8
100-6.340015701.8
125-647018501.6
160--55021301.6
200--63025301.4
250--72027601.4
500--116048801.2
800--1520696018
1250--209096901
2000--3050144500.8
Manufacturing 1
Manufacturing 2
Epoxy Resin

Epoxy Resin Encapsulation

Non-Epoxy Resin

Non-Epoxy Resin Cast Solid Insulation Encapsulation

Isolation Transformer

Isolation Transformer

Company Profile
Frequently Asked Questions
Are you a manufacturer or a trading company?
We are a professional transformer, box substation, high and low voltage switchgear manufacturer with more than 30 years' experience. Support OEM & ODM.
Why should you buy from us not from other suppliers?
30 years experience, Exported to 80+ countries, 250,000 m² Workshop, 58+ Patents, Annual output of 30,000 units, ensuring on-time delivery.
What certificates and standards do you have?
IEC, CE, ISO14001, ISO 45001, CQC, BV, GOST standard compliant.
What products do you produce?
15KVA - 31500KVA, 6kV~35kV Oil Immersed Transformers; 30KVA - 5000KVA, 6.6kV~35kV Dry Type Transformers; Compact and Pad-Mounted Transformer Substations; High and Low Voltage Switchgear.
Do you accept FAT (Factory Acceptance Test)?
Yes. It’s available. CNAS certified laboratory, each transformer undergoes more than 10 rigorous tests to ensure stable operation in all environments.
How do you ensure product quality?
Through rigorous material inspection, advanced manufacturing processes, and comprehensive testing in our certified facilities before every shipment.
