| Rated Capacity (KVA) |
Voltage Combination | Connection Symbol | No-load Loss (KW) |
Load Loss (KW) |
No-load Current (%) |
Short-circuit Impedance (%) |
|||
|---|---|---|---|---|---|---|---|---|---|
| High Voltage (KV) |
Tapping Range (%) |
Low Voltage (KV) |
|||||||
| S13-M-L-30/10 | 6 6.3 6.6 10 10.5 |
±5 ±2×2.5 |
0.4 | Yyno Dyn11 |
0.08 | 0.57 | 0.38 | 4 | |
| S13-M-L-50/10 | 0.11 | 0.83 | 0.30 | ||||||
| S13-M-L-63/10 | 0.12 | 1.00 | 0.26 | ||||||
| S13-M-L-80/10 | 0.15 | 1.20 | 0.25 | ||||||
| S13-M-L-100/10 | 0.18 | 1.43 | 0.25 | ||||||
| S13-M-L-125/10 | 0.21 | 1.71 | 0.23 | ||||||
| S13-M-L-160/10 | 0.24 | 2.10 | 0.23 | ||||||
| S13-M-L-200/10 | 0.31 | 2.55 | 0.23 | ||||||
| S13-M-L-250/10 | 0.34 | 3.90 | 0.22 | ||||||
| S13-M-L-315/10 | 0.40 | 3.47 | 0.21 | ||||||
| S13-M-L-400/10 | 0.47 | 4.09 | 1.21 | ||||||
| S13-M-L-500/10 | 0.58 | 4.85 | 1.20 | ||||||
| S13-M-L-630/10 | 0.70 | 5.89 | 0.20 | ||||||
| S13-M-L-800/10 | 0.80 | 7.10 | 0.19 | ||||||
| S13-M-L-1000/10 | 1.00 | 9.78 | 0.17 | ||||||
| S13-M-L-1250/10 | 1.10 | 11.40 | 0.16 | 4.5 | |||||
| S13-M-L-1600/10 | 1.30 | 13.70 | 0.16 | ||||||
