Transformer Introduction
Pad Mounted Transformer
Technical Description:
Primary voltage: up to 36kV
Secondary voltage: 120/240/480/600V
Rating power: up to 333 kVA
Single Phase Pad Mounted Transformer General
- A complete line of single phase residential pad mounted distribution transformers is manufactured in the Power™ series product line. They are available in standard ratings and configurations or can be customized to meet specific needs.
- Three-phase transformers are available as ANSI I & II transformers. All of these distribution transformers are oil-insulated, selfcooled, available in loop or radial feed, and are dead-front.
- All of these transformers meet or exceed ANSI®, IEEE® and NEMA® standards.
- The ANSI® and IEEE® Type-1frontplate arrangement allows vertical feed to the primary and secondary bushings. It is ideal for single-phase industrial and residential applications where a wide range of kVAs or heavy cabling is required.
1 Phase Pad Mounted Transformer Advantage
- Strong overload capacity, does not affect the service life.
- Energy saving and environmental protection, Stable operation.
- Three-phase five-column structure, the voltage quality is high, the neutral point does not drift, the cabinet does not generate heat, the noise is low, and the lightning protection performance is good.
Residential Pad Mounted Transformer Applications
- Padmounted transformer usually installed at streets, parks, hotels, countryside, residential or commercial areas.
Single Phase Pad Mounted Transformers Design
- Compartmental available in live-front or dead-front design.
- Critical load designed with special attention to surge protection.
- Hardened data center designed with special attention to surge protection, providing superior performance under the most stressful electrical environments.
- Solar specifically designed for Solar Photovoltaic generator step-up (GSU) applications.
- Vacuum fault interrupter combines both voltage transformation and either transformer or loop overcurrent protection in one space-saving, money-saving package.
- Can be located near or inside buildings for greater flexibility and savings.
Ground Pad Mounted Transformer Transport Packaging
Outdoor pad mounted distribution transformers are packed with plastic cloth, and the corners are protected with pearl cotton and wrapped with winding film.
| Phase |
Single Phase |
| Power Usage |
Power |
| Rated Primary Voltage |
7.2kv/7.62kv/7.957kv/12.47kv/13.2kv/13.8kv/14.4kv |
| Rated Secondary Voltage |
120/240V/240/347V/480V/600V |
| Rated Power |
up to 500kVA |
| Frequency |
Frequency |
| Winding material |
Dyn11/Yyn0/Yd11/YNd11 |
